Linear actuators

compact design, comprehensive range, high IP rating, long life, different materials & surface treatments

SIR Srl started its humble beginnings in 1986, in a small facility in Cormano, Italy, where it first started producing gearboxes. Today, the company’s product range has evolved, and now SIR have become a renowned specialist in the design and manufacture of Linear actuators and associated drive systems. The company became part of the Amer Group in 1993, which has design and production facilities in various locations around the world. SIR has a strategy of ongoing and continuous investment in new technologies, product developments, production efficiencies and development of their team. As a result they are able to anticipate the fast and dynamic changes of the market and be an active part in the successes of their trading partners.


Powerful Harsh Environment Linear Actuator

The XL-Line right angle linear actuator from SIR is designed for harsh conditions, where a rugged and robust construction is required. Standard enclosure rating is IP65, with forces upto 10,000N. All metal parts have galvanic protection, with the push rod supplied in stainless steel as standard. Customisable stroke and retraction lengths, front and rear fixing options, encoder feedback. Options also include integrated / adjustable limit switches and encoder feedback.

  • Suited For Harsh Enviornments
  • Rugged & Robust Design
  • DC or AC Motor
  • Customisable Stroke & Retraction Length
  • Integrated & Adjustable Limit Switches Available
  • Encoder Feedback Option

Linked Products
Rated ForceUpto 10000N
Rated SpeedUpto 26mm/s
Duty CycleS3 10% (based on 10mins)
IP RatingIP65
Standard Stroke50 - 400mm
(longer lengths available on special request)
Motor Supply12VDC
MaterialMetal body with stainless steel push rod
Operating Temperature-10ºC to +60ºC
CatalogueXL-Line DatasheetPDF 1.9MB
Accessories DatasheetPDF 3.2KB
SIR Main CataloguePDF 9.3MB
DimensionsA0-6/MZIP 980KB
A0-36/M (DC)ZIP 659KB
A0-3ZIP 303KB
A0-36/M (AC)ZIP 747KB
CertificationsISO 9001 CertificatePDF 1.4MB

Technical Information

Product technical details and product downloads

Click Here
