Linear actuators

robust, powerful, comprehensive range, wide choice of options, complete lifting packages

NIASA was founded in 1984 as a result of the expansion of the German group NEFF. 25 years later, NIASA now designs and manufactures a wide range of linear motion solutions used in a variety of industrial sectors. The experience acquired throughout these 25 years, listening to the feedback from their customers, has enabled Niasa to provide leading edge, high quality and reliable linear motion products, renowned in the industrial sector. Due to the experienced technical department, a modern R&D department and a commercial management aimed at forecasting the market needs, Niasa aims to provide strong technical advice on the application of their linear motion products, and generate tailored solutions to meet the needs of their customers. NIASA holds the ISO 9001 :2008 and ISO 1 4001 :2004 certifications and therefore complies with all the essential quality control procedures and environmental regulations which guarantee the reliability of their products. NIASA customers belong to sectors such as automotive, aeronautic, railway, renewable energy, food production and packaging, where quality and service are the two key requirements.

FM-Series

Industrial Linear Actuator

The FM-Series Linear Actuator range from Niasa offers a rated force from 5kN to 100kN, combining an M-Series gear housing with additional piston rod and aluminium or steel cover tube. The FM actuator range offers the benefits of a screwjack with the additional advantage of being able to work under the most demanding environmental conditions with pivoting motion capability. Models include Ball Screw Or Trapezoidal Spindles. The cubic housing allows for universal mounting. Options include manual drive or motorised, AC, DC or servo driven. In addition, Gapp Automation can offer a complete lifting system package (including controls, drives, visualisation, feedback, power transmission).

5kN to 100kN Force
Ball Screw or Trapezoidal Spindle
Options to Allow Pivoting Motion
Variety of Surface Coatings

Technical

Downloads

Linked Products

Enquiries

Rated Force	FM1 - 5kN
	FM2 - 10kN
	FM3 - 25kN
	FM4 - 50kN
	FM5 - 100kN
Reduction Ratio	4:1 - 36:1 (depending upon size)
Travel (mm/input rev)	0.22 - 6.67 (depending upon size)
Linear Speeds	Up To 12m/min (standard versions)
Duty	Up To 30%, Over 10mins (type dependant)
Mounting Orientation	Universal
Options	Special Designs
	Food Grade Specification
	Higher Corrosion Protection
	Range of Paint Colours
	Non-Standard Spindle Pitches
	High/Low Temperature Versions
	Wide Range Of Accessories
